Ratchet Mechanism IWS-SS-4-90 – small 40 105°–165° (with Spring) with Bracket G R+L
Product code: LB-00155-C00
- Quiet operation – smooth and silent performance.
- Integrated angle bracket enables quick and precise installation in the furniture structure.
- Built-in tension spring supports headrest closing, enhancing comfort and extending the mechanism’s lifespan.
The IWS-SS-4-90 Ratchet Mechanism - small 40 105°-165° (with spring) with G P+L bracket is a high-quality component designed for furniture manufacturers who value reliability and precision. Made from steel and coated with white galvanic zinc, it ensures excellent corrosion resistance and long-term durability. The mechanism offers an adjustment range from 105° to 165°, with the ability to set it in four positions and 15° increments, allowing precise positioning within the furniture. Thanks to the integrated spring and G P+L bracket, the mechanism guarantees stability and ease of installation in various furniture structures.
| Unit of measure | set |
|---|---|
| Material | steel |
| Initial angle [°] | 105 |
| Final angle [°] | 165 |
| Number of positions | 4 |
| Adjustment stroke [°] | 15 |
