Friction hinge ICC-W-36-180-Z with gear and angle bracket
Product code: LB-00303-C00
- Bidirectional operation of the mechanism (click-click + friction function) – during opening it operates stepwise with clearly defined positions, while during closing it moves smoothly, allowing it to be returned to the initial position or stopped at any desired setting.
- Practical angle bracket – facilitates stable and precise mounting.
- Multiple positions – allows precise adjustment of the mechanism in various configurations.
Friction hinge ICC-W-36-180-Z with gear and bracket, made of steel with a white galvanic zinc coating, is an advanced solution designed for modern furniture constructions. The starting angle of 90° and the ending angle of 230° provide a wide adjustment range, and the mechanism offers operation in 28 positions during opening. Dual-direction mechanism operation (click-click + friction function) – during opening it works in defined steps with clear positions, while during closing it operates smoothly, allowing both return to the initial position and stopping at any chosen setting, while the bracket ensures stable and secure installation.
| Unit | set |
|---|---|
| Colour | white zinc (electroplated) |
| Initial angle [°] | 90 |
| Final angle [°] | 230 |
| Number of positions | 28 |
